Power consumption for Cabinet/DU/RU [Jun-2026]

Category	Product Name	Band	Technology	High Load (Watt)	Dimension (HxWxD)
Category	Product Name	Band	(Temp @ 55 Deg C)	High Load (Watt)	Dimension (HxWxD)		max. Load Current at -36VDC	Max. fuse rate (A)
AAS Unit	AIR 6488	B42	200 W (DL:100 - UL:00)	1380	819 x 400 x 272		45	50
	AIR 6449	B42	320 W (DL:100 - UL:00)	1638	773 x 403 x 205		40	50
	AIR 6449	B42	200 W (DL:100 - UL:00)	1323	773 x 403 x 205	Max 4W/MHz	40	50
	AIR 6449	B79A	320W (DL:100 - UL:00)	1589	728x 485x 218		40	50
	AIR 6449	B79A	160W (DL:100 - UL:00)	1232	728x 485x 218	Max 4W/MHz	40	50
	AIR 6419	B42	320 W (DL:100 - UL:00)	1383	717 x 408 x 140		40	50
	AIR 6419	B42	200 W (DL:100 - UL:00)	1095	717 x 408 x 140	Max 4W/MHz	40	50
	AIR 3239	B78F	100 W (DL:100 - UL:00)	719	563 x 411 x 178		22	25
	AIR 3227	B42	200 W (DL:100 - UL:00)	1069	540 x 370 x 180	Max 4W/MHz	34	40
	AIR 3268	B42	200 W (DL:100 - UL:00)	997	539x 370x 111	Max 4W/MHz	28	40
	AIR 3255	B78AA	200 W (DL:100 - UL:00)	759	572x 408x 101	Max 4W/MHz	25	32
	AIR 3255	B79A	200 W (DL:100 - UL:00)	827	572x 408x 115	Max 4W/MHz	25	40
	Interleaved 3218 1.7m	B42	320 W (DL:100 - UL:00)	1072	1700x468x180	Based on AIR 3219 B42	33	40
	Interleaved 3218 1.7m	B42	200 W (DL:100 - UL:00)	832	1700x468x180	Based on AIR 3219 B42, Max 4W/MHz	33	40
	AIR 1281 (AC)	N257	Full Power (DL:100 - UL:00)	163	279 x 200 x 130			6
	AIR 1281 (DC)	N257	Full Power (DL:100 - UL:00)	173	279 x 200 x 130		5	10
	AIR 5322 (AC)	N257	Full Power (DL:100 - UL:00)	271	279 x 200 x 110			6
	AIR 5322 (DC)	N257	Full Power (DL:100 - UL:00)	264	279 x 200 x 110		9	10
Classic Radio	Radio 8823	B42G	8x20 W (DL:100 - UL:00)	756	495 x 343 x 146	8T8R / 2x 4T4R/ 4x 2T2R	20	25
	Radio 8863	B78AA	8x20 W (DL:100 - UL:00)	805	478 × 375 × 155		45	50
	Radio 8863	B78AA	8x40 W (DL:100 - UL:00)	1262	478 × 375 × 155		45	50
	Radio 4422	B78Q	4x40 W (DL:100 - UL:00)	618	430 x 342 x 150		25	32
	Radio 4422	B42F	4x40 W (DL:100 - UL:00)	652	430 x 342 x 150	4T4R / 2x 2T2R	25	32
Radio Dot Solution	IRU8846	NA	NA	72				16 (AC) / 25 (DC)
	IRU8848	NA	NA	69				16 (AC) / 25 (DC)
	IRU1648	NA	NA	128				16 (AC) / 25 (DC)
	IRU1649	NA	NA	121				16 (AC) / 25 (DC)
	IC-8855	NA	NA	100				15 (AC) / 30 (DC)
	RD 4479	N78A	Full Power (DL:100 - UL:00)	44
	RD 4474	B78U	Full Power (DL:100 - UL:00)	45
	RD 4475	B78U B1 B3	Full Power (DL:100 - UL:00)	57
	DoT 4455	B78U B1 B3	Full Power (DL:100 - UL:00)	72
	DoT 4459	B78U	Full Power (DL:100 - UL:00)	35

Remarks:
For power supply dimensioning, please add 20% margin to the high load power consumption of the corresponding hardware.

發表者: webadmin 於 2026-09-04 @ 11:44 Asia/Hong_Kong (32 次閱讀)
(發表回應？ | 分數： 0)

Smartone Site No#

1	Band	Code	Site ID#
2	U850 :	W5	81358
3	U2100 :	W1	85339
4	L700 :	B28	No Service.
5	L850 :	B5	75339 / 7XXXX
6	L900 :	B8	15339 / 1XXXX
7	L1800 :	B3	95339 / 9XXXX
8	L1800C2 :	B3	45339 / 4XXXX
9	L2100 :	B1	35339 / 3XXXX
10	L2300 :	B40	No Service.
11	L2600 :	B7	25339 / 2XXXX
12	N2100 :	N1	535339 / 53XXXX
13	N1800C2 :	N3	545339 / 54XXXX
14	N700 :	N28	705339 / 70XXXX
15	N850 :	N5	575339 / 57XXXX
16	N3500 :	N78	305339 / 30XXXX
17	N4900 :	N79	405339 / 40XXXX

發表者: webadmin 於 2026-07-03 @ 15:56 Asia/Hong_Kong (88 次閱讀)
(發表回應？ | 分數： 0)

RRI / AIR Code

KRD901120/11 -- AIR 6449 (B79)

KRD901213/11 -- AIR 3268 (B42)

KRC161905/1 --- RRU 4499 (850/700)

KRC161950/1 --- RRU 4490 (2100/1800)

KRC161822/1 --- RRU 8823 (3500)

發表者: webadmin 於 2026-03-25 @ 09:26 Asia/Hong_Kong (167 次閱讀)
(發表回應？ | 分數： 0)

Bespark Tel

Telephone Intercom ID & Direct Line
PK Wong	889	Direct Line 2262 9999
FA Dept		MT/ IRDS Dept
Cherry Wong	952	WH Cheng 康	977
Connie Zhu	955	LeeYeeKei 几	979
Katherine Lai	983	Vivien Hui	916
June Leung	922	Kennis Wu	789
EM Dept		TC Dept
Nevilie Lee	909	Annie Chan	928
Bowie Cheng	915	Dara Law	939
Tony Lam	968	Nicki Hon	888
Procurement Dept		Catherine Lau	989
Lorraine Cheng	901	Steve Chan	930
Meeting Room		Patrick Leung	908
Meeting Rm	960	Yun Mak	941
Conference Rm	980	KK Fung	940
		Kenneth Tsang	988

發表者: webadmin 於 2025-09-15 @ 12:25 Asia/Hong_Kong (155 次閱讀)
(發表回應？ | 分數： 0)

Install Ricoh agent

Install Ricoh agent : rpass.rhkcloud.com/deploy/#/h-cua-103771.pc

Install Ricoh Security Software : es_installer_edragent

發表者: webadmin 於 2025-09-12 @ 13:06 Asia/Hong_Kong (169 次閱讀)
(發表回應？ | 分數： 0)

SMC Provided Fiber

Product Code	Description	Type
RW-79084106	Outdoor Optical Fiber Cable Jumper LC Duplex – LC Duplex PDLC18 Connector, Length 50 Meters	AAU 3268
RW-79084108	Outdoor Optical Fiber Cable Jumper LC Duplex – LC Duplex PDLC18 Connector, Length 80 Meters	AAU 3268
RW-79082406	Outdoor Optical Fiber Cable Jumper LC Duplex – LC Duplex Connector, Length 50 Meters	RRU
RW-79082408	Outdoor Optical Fiber Cable Jumper LC Duplex – LC Duplex Connector, Length 70 Meters	RRU
RW-79082410	Outdoor Optical Fiber Cable Jumper LC Duplex – LC Duplex Connector, Length 100 Meters	RRU
RW-79082411	Outdoor Optical Fiber Cable Jumper LC Duplex – LC Duplex Connector, Length 150 Meters	RRU

發表者: webadmin 於 2025-02-13 @ 11:54 Asia/Hong_Kong (253 次閱讀)
(發表回應？ | 分數： 0)

Coupler and Cable Loss

Coupler	Coupled	Through	Coaxial Cable	Cable/M
3db	3.5db		1/2" Cable	0.11db
6db	6.5db	2db	7/8" Cable	0.061db
10db	10.5db	1db	1-1/4 Cable	0.045db
15db	15.5db	1db	1-5/8" Cable	0.04db
20db	20.5db	1db	Lift Cable	0.73db

發表者: webadmin 於 2024-11-22 @ 10:15 Asia/Hong_Kong (207 次閱讀)
(發表回應？ | 分數： 0)

PMH Submission IEC 60332

IEC 60332-1 標準由三個小節組成：

IEC 60332-1-1 第 1-1 部分：單根絕緣電線或電纜的垂直火焰傳播測試 – 設備
IEC 60332-1-2 第 1-2 部分：單根絕緣電線或電纜的垂直火焰傳播測試 - 1 kW 預混合火焰的程序
IEC 60332-1-3 第 1-3 部分：單根絕緣電線或電纜的垂直火焰傳播測試 - 識別燃燒液滴/顆粒的程序

根據 IEC 60332-1-2 標準，防火測試通過火焰蔓延來評估電纜的防火特性。歐盟國家 CE 標誌的基礎是根據 EN 13501-6 標准進行防火分類。此分類包括根據 IEC 60332-1-2 標準中描述的測試方法進行防火測試。該方法構成了火災類別的基礎。除了CE標誌之外，該方法還提供了有關電纜防火特性的重要信息，因此經常用於產品開發和工藝優化。

測試時，用適當尺寸的銅線將樣本垂直固定在兩個水平支架上。IR。放置燃燒器，使火焰的內部藍色錐體在距離上水平支撐件下邊緣 475 mm 處撞擊樣品表面，並且燃燒器呈 45 度角。火焰暴露時間取決於電纜直徑。

發表者: webadmin 於 2024-10-07 @ 14:30 Asia/Hong_Kong (229 次閱讀)
(發表回應？ | 分數： 0)

All band for HGC

Local Cell ID	Subrack No.	RRU Chain No.	Sector	DL EARFCN	UP EARFCN	Center Frequency Downlink (MHz)	Center Frequency uplink (MHz)	Downlink Bandwidth	Band

0		60	Sector 1	1751 1750	19751 19750	1860.1 1860	1765.1 1765	10M 10M	L1800
1		61	Sector 2
2		62	Sector 3
200			Sector 1	1925	19925	1877.5	1782.5	5M	L1800 C2
201			Sector 2
202			Sector 3
20		70	Sector 1	39350	39350	2370	2370	20M	L2300A
21		71	Sector 2
22		72	Sector 3
40			Sector 1	39494	39494	2384.4	2384.4	10M	L2300B
41			Sector 2
42			Sector 3
160	130	130	Sector 1	9260	27260	763	708	10M	L700
161	131	131	Sector 2
162	132	132	Sector 3
60		80	Sector 1	3575 3649 3550	21575 21649 21550	937.5 944.9 935	892.5 899.9 890	5M 5M 10M	L900
61		81	Sector 2
62		82	Sector 3
80	90	90	Sector 1	499 500 524	18499 18500 18524	2159.9 2160 2162.4	1969.9 1970 1972.4	10M 10M 10M	L2100
81	91	91	Sector 2
82	92	92	Sector 3
341	110	110	Sector 1	638666	638666	3579.99		40M	N78 (NR3500)
342	111	111	Sector 2
343	112	112	Sector 3
321	110	110	Sector 1	621000 620952		3315 3314.280		30M 30M	N77 (NR3300)
322	111	111	Sector 2
323	112	112	Sector 3
381		90	Sector 1	431980 432030	--- 394000	2159.9 2160.15		10M 15M	N1 (NR2100)
382		91	Sector 2
383		92	Sector 3
461	160	130	Sector 1	152600	141600	763		10M	N28 (NR700)
462	161	131	Sector 2
463	162	132	Sector 3
	GB			2850 3125	20850 21125	2630 2657.5	2510 2537.5	20M 15M	GB - 2600
